Blue Sea 7046 187 – Series Thermal Circuit Breaker – 120Amp
Original price was: $165.52.$122.61Current price is: $122.61.
(-26%)- Free Delivery: Spend $100.00 or more and receive free shipping
- 24/7 Support: We’re here to help anytime you need us.
- Exclusive Offers: Sign up for our newsletter to receive exclusive deals and discounts.
Product details
187 – Series Thermal Circuit Breakers – Panel Mount
120 Amp Circuit Breaker
PN: 7046
Features:
- Combines switching and circuit protection into a single device
- All components meet SAE J1171 external ignition protection requirements
- Clear, single lever operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Waterproof
- Recessed mounting holes for clean appearance
- Self-trimming case eliminates the need for mounting panels or trim bezels
- Round case permits easy installation with standard sized hole saw
- Large clearance around terminal studs accept heavy gauge wire lugs
- Robust 5/16 terminals provide high torque connections
- Large lever with vertical/horizontal orientation provides indication of trip status
- Ignition protected – safe for installation aboard gasoline powered boats
| Specifications | |
| Circuit Breaker Class: | Type III – Switchable / Manual Reset – Trip Free |
| Type: | Thermally Responsive Bi-Metal Blade |
| Case Material: | Thermoset Polyester |
| Voltage Rating: | 48 Volts DC Maximum |
| Interrupt Rating: | 5,000 Amperes @12 Volts DC |
| 3,000 Amperes @24 Volts DC | |
| 1,500 Amperes @42 Volts DC | |
| Operating Temperature Range: | -25C° to +82C° |
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Additional information
| Weight | 0.5 kg |
|---|---|
| Dimensions | 8 × 5 × 2 cm |
| UPC | |
| Manufacturer Part Number | |
| Manufacturer Name | |
| Country of Origin |
